Smart Lock Technologies Inc.
|
Model: MMW1620 EasyFit MagWell How its made: High pressure plastic injection mould technology. Materials: Glass fill nylon. Introduced: Not yet released due out early December 2004. Facts: Will fit on 4 and 5 inch barreled model XD`s. Company info: Recoil Control Thumb Rest for Glock pistols are #12 in the most inquired products featured in Law Enforcement Products News. As featured in the January/February 2004 issue. Manufactures website: www.smartlock.com MSRP: $22.00 |
 and when installed it blends right in with the rest of the grip of the XD. This magazine well comes assembled ready for  the half round channel located at the bottom rear (red Arrow) of the grip on the XD and HS2000 pistols. The magwell has three cuts (red arrows below left) on an extension that fit inside of this channel. Push up on the magwell Until it is fully seated, and it is ready for use. The magwell has a tight fit in the pistol's channel and will take some effort to remove. For those that
 the magwell is a hole (above arrow right) for the included small retaining screw. Once the magwell is attached and fully seated just insert the retaining screw into the hole, using a fine philips screwdriver. Screw the retaining screw in until the head touches the base of the magwell and you are set. The magwell will not fall off until the screw is removed. Now there are two warnings 1: You will put a small hole in the back of your pistol's polymer handle, but it is very small and is almost unnoticable. If you plan to add and remove the magwell a lot you may not want to use the screw as every time you reinstall the magwell it will be dificult to exactly match up the screw holes in both the pistol and magwell. The good news is that unless you are just a gorrilla and very abusive the mag well fits very tight and should stay with any normal usage even if you do not use the screw. 2: When tightening the retaining screw, you only have to tighten enough for the base of the screw head to touch the base of the magwell. If you continue to tighten you will strip the polymer on the grip and the nylon on the magwell. The good news on this is just tigten enough that the screw no longer moves and you are done. It is that simple.  simplest is just to pull the magwell back off by Slowly pulling at the rear of the magwell and popping it right out. The second, if you just want to get rid of the large funnel portion of the magwell, you can remove just that. On the bottom of the magwell is a large screw (above arrow). If you remove the screw then you can remove just the funnel leaving the plug portion in place.
 finger may ride the top edge of the magwell. The magwell does as it is supposed to and adds width to the pistols grip so using this magwell for concealed carry may not be the best option. In competition the larger magwell and the easy fit can cut down reload times and help fix a sloppy reload. The funnel opens the xd and hs2000`s magwell by about a half inch. You can almost insert a magazine faced side ways and still finish a tactical reload in good time by twisting the mag while pushing up. Now most aftermarket magwells require the use of some type of extended magazine base pad, however the xd magwell does not require this. If using the stock base pad while reloading, keep your palm flat while pushing up on the magazine and slaming it home. No extended base pad is needed to remove the magazine either. Occasinally magazines get stuck in pistols and have to be pulled out in a hurry. You can still do this with the EasyFit magwell because the magwell does not enclose all of the bottom of the grip. The magwell is open at the front end so it is easy to pull a magazine out of  pull at it for no reason, but it will snap back to its original position if flexing occurs while reloading during use. The magwell only adds 0.34 oz to the total weight of the pistol and will fit any HS2000 or XD in the 4 or 5 inch barreled versions. The magwell can be made to work with the subcompact if the inside two arms that fit in the channel are filed down a bit. The channel of the subcompact has an extra "growth" in it so the trimming is required to get around that. If you are able and willing to put in a little work at fitting you can have a magwell on a subcompact XD. To make things better the EasyFit MagWell for the XD and HS2000 pistols comes with a 5 year limited warranty for more information check out Smart Lock Technologies Inc at their website www.smartlock.com.  testing was done becuase this was my only sample. But over all no major problems occured while using the the magwell so no extreme testing was needed. As with any new product added to a firearm you will still have to practice to learn how to use it. Smart Lock Technologies put a lot of work and effort into this MagWell and it shows. For those of you do-it-yourselfers that are looking to further customize your XD or HS2000, the MagWell can give you an inexpensive non-permanent and functional option that does not only gives you the potential for better scores but sets you apart as well. |
The mag well shown on the XD with and without a magazine inserted.
Here an XD is shown with the Recoil Control Thumb Rest, GripPlus Memory Groove
and the EasyFit MagWell.
The rear of the XD showing the retainer screw as well as the front and back of the magwell.
More information as well as a full product review will follow shortly as available.
